Benchtop Dental Zirconia Milling Machine Dental Laboratory Automatic Material Changer Tool management

Packaging Details : Wooden crate

Length/Width/Height : 605mm*970mm*680mm

Spindle Speed : 0-60000rmp

Processing Method : Dry

Spindle cooling method : Air cooling

Store Burs : 5 Burs

Air consumption : 50L/min

Rotation Axis Angle : A: 360°, B: ±30°

Brand Name : Beaming

Model Number : SK-10A

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : 9800 - 25000USD 1 pcs

Payment Terms : T/T

Supply Ability : 1 pcs 7-15 days

Voltage : 220V

Milling Accuracy : ±0.01mm

Delivery Time : 7-15 days

Frequency : 50/60Hz

Machinable Materials : Zirconia,Wax,Resin,Composite Materials

Automatic material replacement : 10 disc materials

Weight : 170kg

Rated power : 1000W

Contact Now

SK 10A Benchtop 5 Axis Dental Zirconia Milling Machine Automatic Material Changer with 10-Slot Magazine
Product Overview

The SK-10A represents an automated 5-axis dental milling platform featuring robotic material handling. Engineered for continuous dry processing of zirconia, resins, and wax blocks, it incorporates a 10-position modular magazine for unattended operation. With industrial-grade servo drives and 60,000 RPM spindle capability, the system achieves ±0.01mm dimensional accuracy for dental restorations.

Benchtop Dental Zirconia Milling Machine Dental Laboratory Automatic Material Changer Tool management
Clinical Applications

This solution supports comprehensive restoration workflows:

  • Fixed Prosthetics: Full crowns, inlays, bridges, implant crowns
  • Temporary Solutions: Provisional resin crowns/bridges and wax patterns
  • High-Volume Production: 24-hour automated processing cycles
Benchtop Dental Zirconia Milling Machine Dental Laboratory Automatic Material Changer Tool management
Operational Benefits
  • Automated Production Efficiency: Robotic material cycling enables continuous processing across 10 material positions, reducing operator intervention during extended workflows.
  • Precision Machining Performance: Closed-loop servo control with precision ball screws maintains ±0.01mm tolerance across diverse materials.
  • Extended Production Capability: Sustained 24-hour operation supported by quick-change tool management (5-position magazine) and intelligent breakpoint recovery.
  • Material Utilization Enhancement: 118° open-angle fixture with secondary clamping optimizes blank usage during complex restorations.
  • Remote System Management: IoT-enabled access facilitates technical support and maintenance planning.
Benchtop Dental Zirconia Milling Machine Dental Laboratory Automatic Material Changer Tool management
Technical Specifications
Category Specification
Drive System 1,000W closed-loop servo motor
Positional Accuracy ±0.01mm
Spindle Performance 0-60,000 RPM
Tool Management 5-position quick-change magazine
Material Handling 10-slot robotic magazine
Processing Method 5-axis dry milling
Axis Articulation A-axis: 360° * B-axis: ±30°
Fixture System 118° open-angle with secondary clamping
Compatible Materials Zirconia * Resins * Wax * Composites
Tool Specification Φ4mm
Production Mode Continuous 24-hour operation
Benchtop Dental Zirconia Milling Machine Dental Laboratory Automatic Material Changer Tool management Benchtop Dental Zirconia Milling Machine Dental Laboratory Automatic Material Changer Tool management
